Linear Guide Shaft
Specifications:
Model: Size 7to 15, standard and lengthened type
Material: Bearing steel
Accuracy Level: N,H
Length of rail : 100mm-4000mm
Characteristic |
Main uses |
Unique advantages |
The bearing oil chamber of the slide is filled with hydraulic oil, and the pure liquid friction between the slide and the guide rail has good lubricity and vibration absorption. |
●High-precision machining center ● Heavy duty lathes ●Gantry machining center ●Horizontal slide ◆ Laser equipment ● Medical equipment |
●There are lubricating oil chambers inside the slider, which can withstand loads from different directions. ● The installation size is the same as that of ordinary rolling guidance systems. ◆ Frictional resistance hardly changes with load. ◆The rigidity of the pressure direction is comparable to that of the roller slide of the same model. ●Resistant to shock and vibration, it can replace the function of damping slider. |
Applications
Widely used in vertical machining centers, drilling and tapping machines, glass machines, medical equipment, automobile production lines, tire production lines, bottle-blowing machines, palletizing machines, woodworking machinery, etc.
![](/cdn-cgi/image/w=1920,format=auto/files/74308c811f/202302/0cc13e97ec25ea9f5e222f585406bd3.jpg)
Company Advantage
We are an OEM factory, we always provide High quality and Fine after-sales, our linear motion guide is manufactured with Precision processing, Pipelining assembly, and 100% QC process. Plentiful stocks, Fast and Safe shipping are our other advantages over other suppliers.
![](/cdn-cgi/image/w=1920,format=auto/files/882399365d/202304/%E5%BE%AE%E4%BF%A1%E5%9B%BE%E7%89%87_20230407154110.jpg)
Wholesale
We deliver high-quality and any quantity Guide ail cutting machine, Automatic packaging line of guide rail and Automaticendgrinder, End grinding roller frame, Cleaning running in machine and Screw running-in machine to our clients worldwide. If you are a Guide ail cutting machine, Automatic packaging line of guide rail and Automaticendgrinder, End grinding roller frame, Cleaning running in machine and Screw running-in machine distributors, OEM dealers and retailers, feel free to contact us. We welcome big and small orders from you.
